BUS Cable

Hi-flex BUS cables for use in cable carriers

• Network
• Communication with several participants

Our Series are available in different qualities:

• 200/200C: Layer stranded cables with PVC outer jacket for light to medium demands
• 400/400C: Bundle stranded cables with PVC outer jacket for medium heavy demands
• 700/700C: Bundle stranded cables with PUR outer jacket for heavy demands
• 1000/1000C: Bundle stranded cables with TPE outer jacket for really heavy loads

Products of BUS Cable

	Type	Outer jacket material	Shield	Flexibility	Demands	Up to motion cycles	Travel length up to	Stranding
	DATA 400 C	PVC	Shielded	hi-flex	for demanding applications	4 Mio	50 m	Layer stranded
	DATA 700	PUR	Unshielded	hi-flex	for high demandeing applications	7 Mio	200 m	Layer stranded
	DATA 700 TPi C	PUR	Shielded	hi-flex	for high demandeing applications	7 Mio	200 m	Twisted pair stranded
	DATA 700 TPi CD	PUR	Double shielded	hi-flex	for high demandeing applications	7 Mio	200 m	Twisted pair stranded
	DATA 700 TPi CD 1 kV	PUR	Double shielded	hi-flex	for very high demanding applications	7 Mio	200 m	Twisted pair stranded
	DATA 1000 TPi C TPE	TPE	Shielded	hi-flex	for very high demanding applications	10 Mio	400 m	Twisted pair stranded
	DATA 700 TPi CD 1 kV	PUR	Double shielded	hi-flex	for very high demanding applications	7 Mio	200 m	Twisted pair stranded
	DATA 1000 TPi C TPE	TPE	Shielded	hi-flex	for very high demanding applications	10 Mio	400 m	Twisted pair stranded
	DATA 700 TPi CD 1 kV	PUR	Double shielded	hi-flex	for very high demanding applications	7 Mio	200 m	Twisted pair stranded
	DATA 1000 TPi C TPE	TPE	Shielded	hi-flex	for very high demanding applications	10 Mio	400 m	Twisted pair stranded
